功率：3W-70W
精度：±1%~±2%~±5%
阻值：最低0.00005R
温漂：±50 ±100
说明：结构紧凑：高可靠性；高过载能力；极低的电感
特征Features
●过电流能力强Through strong current
●3-70瓦3-70Watts
●精度+5%,+2%和+1 % Tolerance+5%,+2% and +1%
●电阻温度系数+50ppm/°C和+100ppm/9C TCR down to +50ppm/°C and 土100ppm/°C
●阻值低至0.00005欧Resistance values down to 0.00005 ohms
●电感小于10纳亨Low inductance
●符合ROHS要求Lead-free
●AEC-Q200测试合格AEC-Q200 qualified
●特殊规格可以订做Special tolerance is available on request
